S6010-on 1000BASE-T　使用方法

thumbnail
2024/02/11
サーバー

admin@OPX:~$ ip link show
1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN mode DEFAULT group default
    link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
3: eth0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UNKNOWN mode DEFAULT group default qlen 500
    link/ether f4:8e:38:2b:38:69 brd ff:ff:ff:ff:ff:ff
4: npu-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f6:9c:11:44:18:9e brd ff:ff:ff:ff:ff:ff
5: e101-001-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:6a brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 1
6: e101-002-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:6e brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 5
7: e101-003-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:72 brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 9
8: e101-004-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:76 brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 13
9: e101-005-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:7a brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 17
10: e101-006-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:7e brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 21
11: e101-007-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:82 brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 25
12: e101-008-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:86 brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 29
13: e101-009-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:8a brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 33
14: e101-010-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:8e brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 37
15: e101-011-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:92 brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 41
16: e101-012-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:96 brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 45
17: e101-013-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:9a brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 49
18: e101-014-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:9b brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 53
19: e101-015-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:9c brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 57
20: e101-016-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:9d brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 61
21: e101-017-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:9e brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 65
22: e101-018-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:a2 brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 69
23: e101-019-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:a6 brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 73
24: e101-020-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:aa brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 77
25: e101-021-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:ae brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 81
26: e101-022-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:b2 brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 85
27: e101-023-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:b6 brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 89
28: e101-024-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:ba brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 93
29: e101-025-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:be brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 97
30: e101-026-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:c2 brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 101
31: e101-027-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:c6 brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 105
32: e101-028-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:ca brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 109
33: e101-029-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:ce brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 113
34: e101-030-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:cf brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 117
35: e101-031-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:d0 brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 121
36: e101-032-0: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
    link/ether f4:8e:38:2b:38:d1 brd ff:ff:ff:ff:ff:ff
    alias NAS## 0 125
admin@OPX:~$ sudo opx-ethtool e101-001-0
Settings for e101-001-0:
    Channel ID:   0
    Transceiver Status: Enable
    Media Type: SFPPLUS 10GBASE SR
    Part Number: SFP-10G-SR
    Serial Number: ARSSRJ13036
    Qualified: Yes
    Administrative State: DOWN
    Operational State: DOWN
    Supported Speed (in Mbps):  [40000]
    Auto Negotiation : off
    Speed   : 0
    Duplex   : full

admin@OPX:~$ sudo opx-config-fanout e101-001-0 true
Deleting.. e101-001-0
Completed...
Creating interface e101-001-1
Creating interface e101-001-2
Creating interface e101-001-3
Creating interface e101-001-4
Successfully created interfaces...
admin@OPX:~$ sudo ip link set dev e101-001-1 up
admin@OPX:~$ sudo opx-ethtool e101-001-1
Settings for e101-001-1:
    Media Type: SFPPLUS 10GBASE SR
    Part Number: SFP-10G-SR
    Serial Number: ARSSRJ13036
    Qualified: Yes
    Administrative State: UP
    Operational State: UP
    Supported Speed (in Mbps):  [100, 1000, 10000]
    Auto Negotiation : off
    Speed   : 10000
    Duplex   : full

参考資料：OpenSwitch OPX Configuration Guide Release 2.1.0
